200KWh Premium Mobile EV Charging Station – Portable EV Charging

• Efficient energy storage and charging.

• Dual Output (DC 120 kW + AC 40 kW) enables this portable EV charging station to serve multiple vehicles at once..

• Intelligent management system.

• Safety and protection.

• IP54 Protection ensures durability of this mobile EV charging station in harsh conditions.

• Advanced Cooling (liquid + forced‑air) keeps your portable EV charging station running smoothly.

Product Introduction

The 200kWh mobile energy storage charging station is a device that integrates energy storage and charging functions, providing flexible and efficient charging services for electric vehicles.

The 200 kWh Mobile Energy Storage Charging Station redefines mobile EV charging stations. As a fully integrated portable EV charging station, it combines LFP battery cells, Topband’s “1‑Cell, 1‑Cloud, 3S” architecture, BMS/PCS/EMS modules, and a cloud‑based EMS platform. This all‑in‑one system delivers secure, intelligent charging and energy storage, making it the best portable EV charger solution for any field operation.

Application

Emergency Rescue Charging using mobile EV charging stations. Construction Site Power via portable EV charging station modules. Roadside Assistance equipped with the best portable EV charger technology. Outdoor Events & Filming relying on mobile EV charging stations. Microgrid & Zero‑Carbon Campuses enhanced by portable EV charging station flexibility.

: Emergency rescue charging

: Door to door charging service

: Mobile energy storage charging station

: Public place

: Residential communities and enterprises

: Tourist attractions and outdoor activities

: Remote areas and areas without electricity

: Efficient energy storage and charging
Leverage high‑efficiency lithium iron phosphate battery cells for safe, stable energy storage and rapid charging—delivering up to 180 kW output and making it the best portable EV charger for mobile EV charging stations.

: Flexible power supply
Our portable EV charging station supports DC 120 kW and AC 40 kW outputs, making it the best portable EV charger for any on‑the‑go application.

: Intelligent management system
This portable EV charging station offers real‑time remote monitoring and control via mobile app or PC, delivering best portable EV charger intelligence and visibility.

: Flexible configuration and compatibility for mobile EV charging stations

Our portable EV charging station delivers a wide DC output range (200 V–1 000 V) to meet most EV charging requirements and supports CCS1/CCS2 standards, making it the best portable EV charger on the market.

Parameter

Model	TBMC-200-180KW
Parameter category	Parameter	Parameter values
Battery system	Type	LFP
	Battery pack voltage	672V / 716.8V
	Single cell capacity	304Ah
	System combination	210SIP
	Cycle life	>5000 time
Charging parameters	Output power	180kW
	Output voltage range	DC200V~1000V
	Output current	0~250A
	Charging gun parameters	Dual gun 90kW, single gun 180kW
	Range of output voltage for charging gun	200V~1000V
	Charging gun interface	CCS1/CCS2
Power supply	DC power supply	120kW
Power supply	AC power supply	40kW
AC output	AC output power	100kW
AC output	AC output voltage	380V
Environmental parameters	Working temperature range	-10℃~60℃
	Storage temperature range	0℃~40℃
	Working environment humidity	<85%
	IP	Overall IP54, energy storage IP67
Others	Size（LWH）	230014501650 mm / 240013501550 mm
	Weight	2600Kg / ≈2680kg
	Thermal management	Liquid cooling

QHow many safety protections are there?: AOver ten core protections—overvoltage, undervoltage, overcurrent, short‑circuit, leakage, lightning, and more—guard the automatic charging robot.

QWhat about maintenance?: AModular battery packs and cooling modules simplify servicing, backed by Topband’s global support network for your best portable EV charger.

QWhy select Topband’s mobile EV charging stations?: AWith 1 700+ R&D staff, 3 200+ patents, and 10+ global bases, Topband delivers innovation, quality, and on‑time delivery.

QCan it operate off‑grid?: AYes—multi‑source charging (PV, grid, diesel) ensures continuous power for portable EV charging station deployments.

QCan it charge from solar PV?: AAbsolutely—integrated MPPT solar management optimizes PV input for the portable EV charging station.

QWhat safety protections are included?: ATen‑fold protection (over‑current, over‑voltage, short‑circuit, thermal, leakage, etc.) keeps your portable EV charging station safe.

QHow fast can it charge from 0 % to 80 %?: A20 minutes at 180 kW (single connector) or ~30 minutes at full 120 kW output for mobile EV charging stations.

QWhat makes this a true mobile EV charging station?: AIts integrated design—200 kWh LFP cells, BMS/PCS/EMS, IP54 protection, and tow‑ready chassis—defines portable EV charging station excellence.
