Model
|
TBES-550-250KW
|
TBES-600-250KW
|
TBES-1300-630KW
|
TBES-1500-630KW
|
Nominal capacity
|
550 kWh
|
600 kWh
|
1300 kWh
|
1500 kWh
|
Batteries
|
LiFePO4 3.2V 280Ah
|
Rated power
|
250kVA
|
630kVA
|
Output form
|
3W+N+PE
|
Input voltage
|
340~440V
|
Allow input frequency
|
50/60Hz土5Hz
|
Rated input current
|
361A
|
909A
|
Power factor
|
士0.99
|
Overload capacity
|
110% normal operation, 120% running for 1 minute
|
Grid - connect / Grid - disconnected switching
|
Support
|
Rated output voltage
|
400V
|
Rated output frequency
|
50/60Hz
|
Output voltage deviation
|
≤2%
|
Output voltage imbalance
|
≤1%
|
Total harmonic distortion rate of output voltage
|
≤ 3% (pure resistive load)
|
Cooling
|
forced air cooling+Intelligent air conditioning
|
Communication interface
|
RS485/CAN/Ethernet
|
Human computer interaction
|
Touch screen
|
Remote data monitoring
|
Yes
|
Cloud platform integration
|
Yes
|
Working temperature
|
Minus 15 ℃~50 ℃ (reduced capacity above 45 ℃)
|
Working humidity
|
≤ 95% non condensing
|
Altitude
|
≤ 4000m, derating for distances greater than 2000m
|
Weight
|
≤11000kg
|
≤20000kg
|
Dimensions (W × D × H)
|
2991 x 2438 x 2896 mm
|
6058 x 2438 x 2896 mm
|
Fire protection system
|
Perfluoroketone automatic extinguishing device, active protection, equipped with temperature, smoke, carbon monoxide and other detectors
|
